Lumopt
Lumopt
| Item | RJ45 Female Connector |
| Part Number | LPJU5202BONL |
| Part Status | Active |
| Connector Type | Jack |
| Number of Positions/Contacts | 10p8c (RJ45, Ethernet) |
| Application-Lan | Ethernet(NoN PoE) |
| Number of Ports | 1x1 Port |
| Speed | 10/100 Base-T |
| Latch | Up |
| Cores per Port | 4 |
| Orientation | 90° Angle (Right) |
| PCB Mount Angle | SIDE ENTRY |
| Shield EMI Tabs | With |
| LED Option | Green/Yellow |
| PCB | FR4 |
| PCB Retaining Post | T POST |
| Temperature | 0℃ TO 70℃ |
| Bst Circuit | Yes |
| AutomDX | YES |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Turns Ratio RX/TX | 1CT:1CT |
| Configuration RX/TX | T,C |
We are a specialized manufacturer of magnetic telecom and networking components, certificated by ISO9001:2000, RoHS, REACH, CE and UL, owning advanced manufacturing facilities and testing equipment. With an abundant monthly production capacity, we deliver high-quality components within short lead times. Moreover, we provide complete, professional solutions for magnetic components alongside strong technical support.
Main Products:
Our products are widely used in networking and communication equipment such as HUBs, PC cards, switches, routers, PC mainboards, SDH, PDH, IP Phones, and xDSL modems. We export our products globally, covering regions including Europe, North America, and Asia.
Our engineering team is dedicated to identifying, developing, and manufacturing the optimal solutions for our customers' unique requirements.
