Product Description

10/100 BASE-T Ethernet Interface RJ45 Female Connector Tab up 1X2 Harmonica Jack 5-6610197-1

10/100 BASE-T Ethernet Interface RJ45 Female Connector Tab up 1X2 Harmonica Jack 5-6610197-1 Divider
10/100 BASE-T Ethernet Interface RJ45 Female Connector Tab up 1X2 Harmonica Jack 5-6610197-1
10/100 BASE-T Ethernet Interface RJ45 Female Connector Tab up 1X2 Harmonica Jack 5-6610197-1 Divider
Part Number 5-6610197-1
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"/50u"
Cores Per Port 4
Diodes NO DIODES
LED Option GREEN/YELLOW
Latch UP
Number of Ports 1X2
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITH OR WITHOUT
Speed 10/100 BASE-T
Temperature 0 TO 70°C/-40 TO 85°C
Turns Ratio RX 1CT:1
Turns Ratio TX 1CT:1

Why Choose Us

World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers
Professional Certification
  • ISO 9001:2008
  • UL Certification
  • Reach Certification
  • RoHS Compliance
  • Active Environmental Policy
100% Guarantee Quality
  • Manufactured Under Strict Controls
  • 100% Tested (Not Just Batch Tested)
  • Quality Guarantee: 6 Years
Competitive Price And Service
  • Highly competitive market pricing
  • Delivery Time: 2-3 Weeks After Orders
  • Free Samples Are Available
  • Provide New Design For Customer Requirements
  • Excellent global delivery capabilities and optimization on freight cost
Corporate Policy
  • The Corporate Goal Is To Achieve The Highest Level Of Customer Satisfaction Through Continuous Improvements In Quality, Delivery And Service
  • Committed To And Expects Quality Performance From Every Employee
  • The Company Standard Is Defect-Free Products And Services
Technical Drawing 1
Technical Drawing 2
Technical Drawing 3
Technical Drawing 4
Preferred Supplier for Top Tier Global Electronics Manufacturers
10/100 BASE-T Ethernet Interface RJ45 Female Connector Tab up 1X2 Harmonica Jack 5-6610197-1 Divider
Manufacturing Facility 1
Manufacturing Facility 2

10/100 BASE-T Ethernet Interface RJ45 Female Connector Tab up 1X2 Harmonica Jack 5-6610197-1

Frequently Asked Questions (FAQ)
What are the main application scenarios for the 5-6610197-1 RJ45 connector?
This connector is specifically designed for 10/100 BASE-T Ethernet network applications, commonly used in network switches, routers, industrial PC motherboards, hubs, and other network communication equipment that require high reliability.
Does this 1X2 Harmonica Jack support automatic MDI/MDIX cross-identification?
Yes, it features integrated AutoMDIX support, which enables the connector interface to automatically detect and configure the connection type, removing the need for crossover network cabling.
What are the optional LED configurations for this RJ45 connector?
The standard configuration for this RJ45 Harmonica Jack includes Green and Yellow LEDs to indicate network connection status and speed activity.
What options are available for the contact mating area gold plating thickness?
To suit different durability and performance standards, we offer gold plating thickness options of 6u", 15u", 30u", and 50u" in the contact mating area.
What are the operational temperature limits for this connector?
This connector is designed to function stably across a wide standard range from 0°C to 70°C. Additionally, an extended industrial grade configuration is available which operates from -40°C to 85°C.
Is this product RoHS compliant?
Yes, the 5-6610197-1 complies with the RoHS-5 standard, utilizing the environmental guidelines with lead-in-solder exemption.
