| Part Number | 1840538-3 6610128-1 1840538-4 1840538-2 |
| Application-LAN | ETHERNET(Non POE) |
| AutoMDIX | YES |
| Bst Circuit | YES |
| Configuration RX | T,C |
| Configuration TX | T,C |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Cores Per Port | 6 |
| Diodes | NO DIODES |
| LED Option | GREEN/GREEN |
| Latch | UP |
| Number of Ports | 1x2 |
| PCB | FR4 |
| PCB Mount Angle | SIDE ENTRY |
| PCB Retaining Post | T POST |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Search | YES |
| Shield EMI Tabs | WITH |
| Shielding | Shielded |
| Speed | 10/100 Base-T |
| Temperature | 0℃ ~ 70℃ |
| Turns Ratio RX | 1CT:1 |
| Turns Ratio TX | 1CT:1 |
World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers
This connector is specifically designed for 10/100 Base-T non-PoE Ethernet LAN applications, offering robust data connectivity for network-capable hardware.
These connectors are fully shielded and equipped with EMI tabs to provide effective electromagnetic interference protection, ensuring a stable connection.
Yes, it features AutoMDIX support with 1CT:1 turns ratio configurations for both transmitter (TX) and receiver (RX).
The connector is designed to operate reliably within a commercial temperature range of 0℃ to 70℃.
Yes, it complies with RoHS standards (specifically RoHS-5 with lead-in-solder exemption) and meets international environmental policies.
It features a side entry (right angle) PCB mounting layout with T-post retaining posts and THT (Through-Hole Technology) solder pins.
